Waterproof 16mm Latching Switch Ring Power Logo Design LED Light High Security

Name: Waterproof 16mm Latching Switch Ring Power Logo Design LED Light High Security
Brand: YUESHUN
Price: 1 USD

Brand Name : YUESHUN

Model Number : LA16 illuminated Series

Certification : CE RoHS

Place of Origin : Wenzhou, China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T to our company account or by paypal

Supply Ability : 5000Pcs/Day

Delivery Time : 3-7 work days

Packaging Details : The product is packed in foam box to prevent damage during transportation.

LED color : Red,Green,Yellow,Orange,Blue,White,Purple

Led Voltage : 3V 6V 12V 24V 36V 110V 220V

Protection Level : IP 67

Mechanical life : More than1,000,000 cycles

Mounting panel thickness : 1-10 mm

Operation Distance : About 2 .8 mm

Contact Now

16mm Illuminated Latching Push Button Switch Ring Power logo design LED light Waterproof Pushbutton

Product Description

- Outside color: 1. Stainless steel 2. Nickle plated brass 3. Gold plated brasss 4. Black Zin-Al
- It has an operating life of more than 500,000 cycles,You don't have to worry about replacing them often,It's a very reliable product.
- It is meets ROHS Requirement ,passed the CE certification,which is a kind of push button switch that can be used safely.

Product Specification

- Led Color : Red,Green,Yellow,Orange,Blue,White,Purple or Double color mixing Can be customized.

- Led Voltage : 3V 6V 12V 24V 36V 110V 220V for choose.

- Led Type : Ring , Dot , Power , Angle eye , Trumpet etc. Logo customization are available.

Model Number	LA16 illuminated Series
Mounting Hole	16mm
Max.Switch Rating	Ith : 5A Ui : 250V AC
Material	Body Material: Stainless Steel/Nickel Plated Brass/Black Oxidized Aluminum
	Button Material: Stainless Steel/Black Oxidized Aluminum
	Contact Material: Silver Alloy
	Base Material: PBT
The Front Shape	Flat Round Head
Terminal Type	Pin Termlmal
Switch Operation	Latching or Momentary
Contact Configuration	1NO + 1NC or 2NO + 2NC
Mounting panel thickness	1-10 mm
Operation Distance	About 2.8 mm
Protection Level	IP67
Operating Temp	-20℃～+55℃
